Brother TD-4520TN


Reliable and compact label & barcode printing

The Brother TD-4520TN is a space-saving, professional printer that combines durability with outstanding print precision. Delivering 300 dpi resolution and supporting both thermal transfer and direct thermal modes, it creates sharp, long-lasting labels up to 112 mm wide (usable width 105.7 mm).

With print speeds reaching 127 mm/sec (5 ips), it reduces downtime and boosts productivity. Connectivity is simple with USB 2.0, Ethernet LAN (10/100 Mbps), and RS-232 serial ports. Supplied with Seagull BarTender UltraLite label software at no cost.

This printer is capable of producing labels for pallets, cartons, cardboard, glass, plastics, and metals, and it supports a wide variety of 1D and 2D barcode symbologies.

Why choose Brother TD-4520TN

High-resolution icon
High-resolution printing
300 dpi ensures clear text and barcode readability.

Media compatibility icon
Versatile media handling
Suitable for pallets, cardboard, plastics, metals, glass.

Connectivity icon
Flexible connectivity
USB, Ethernet, RS-232; supports ZPL/ZPL2, EPL, DPL.

Technical specifications

Printing technology Thermal transfer / Direct thermal
Resolution 300 dpi (12 dots/mm)
Max print width 105.7 mm (usable up to 112 mm)
Max print speed 127 mm/sec (5 ips)
Max media width 112 mm
Max print length 11,430 mm (450 in)
Supported barcode types Linear: Code128, EAN-8/13, ITF-14, Code39, MSI, POSTNET, LOGMARS; 2D: PDF417, DataMatrix, QR Code, Aztec, GS1 DataMatrix etc.
Connectivity USB 2.0, USB host, Ethernet LAN, RS-232C serial
Memory 64 MB SDRAM, 128 MB flash
Software Seagull BarTender UltraLite included
Dimensions (W x D x H) 204 × 280 × 177.5 mm
Weight 2.5 kg
Operating temp./humidity 5 °C to 40 °C / 25–85% RH (non-condensing)
